PRODUCT HIGHLIGHTS
The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP/KFRP/STEEL) are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black or colored LSZH sheath.
Characteristics:
· Special low-bend-sensitivity fiber provides high bandwidth and excellent communication
transmission property;
· Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber;
· Single steel wire or messenger as the additional strength member ensures good performance of tensile strength;
· Simple structure, light weight and high practicability;
· Novel flute design, easily strip and splice, simplify the installation and maintenance;
· Low smoke, zero halogen and flame retardant sheath.
transmission property;
· Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber;
· Single steel wire or messenger as the additional strength member ensures good performance of tensile strength;
· Simple structure, light weight and high practicability;
· Novel flute design, easily strip and splice, simplify the installation and maintenance;
· Low smoke, zero halogen and flame retardant sheath.
OVERVIEW
Optical Characteristics:
G.657 | 50/125μm | 62.5/125μm | |||
G.652 | |||||
Attenuation | @850nm | ≤3.5 dB/km | ≤3.5 dB/km | ||
(+20℃) | @1300nm | ≤1.5 dB/km | ≤1.5 dB/km | ||
@1310nm | ≤0.40 dB/km | ≤0.40 dB/km | |||
@1550nm | ≤0.30 dB/km | ≤0.30dB/km | |||
Bandwidth (Class A) | @850nm | ≥500 MHz·km | ≥200 MHz·km | ||
@1300nm | ≥500 MHz·km | ≥500 MHz·km | |||
Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
Cable Cut-off Wavelength | ≤1260nm | ≤1260nm |
Optical Characteristics:
Fiber count | Cable Diameter mm | Cable Weight kg/km | Tensile Strength Long | Crush | Bending Radius Static /Dynamic mm |
/Short Term N | Resistance Long | ||||
/Short Term N/100mm | |||||
1 | (2.0±0.)×(5.0±0.2) | 20 | 300/600 | 1000/2200 | 20/40 |
2 | (2.0±0.2)×(5.0±0.2) | 20 | 300/600 | 1000/2200 | 20/40 |
4 | (2.0±0.2)×(5.0±0.2) | 20 | 300/600 | 1000/2200 | 20/40 |
6 | (2.5±0.2)×(6.0±0.2) | 24 | 300/600 | 1000/2200 | 20/40 |
8 | (2.5±0.2)×(6.0±0.2) | 24 | 300/600 | 1000/2200 | 20/40 |
12 | (2.0±0.)×(5.0±0.2) | 20 | 300/600 | 1000/2200 | 20/40 |
